TIS100-59-A1 High Insulation Silicone Thermal Sheet For Car Battery

Name: TIS100-59-A1 High Insulation Silicone Thermal Sheet For Car Battery
Brand: CÔNG TY TNHH CÔNG NGHỆ ZIITEK VIỆT NAM
SKU: TIS100-59-A1
Price: 4.10 USD
Availability: InStock

Product Details

Place of Origin: Vietnam

Brand Name: Ziitek

Certification: UL and RoHs

Model Number: TIS100-59-A1

Payment & Shipping Terms

Minimum Order Quantity: 1000pcs

Price: 0.1-10 USD/PCS

Packaging Details: 24*13*12cm cartons

Delivery Time: 3-5 work days

Payment Terms: T/T

Supply Ability: 100000pcs/day

Get Best Price

Product Details

Product Description

Highlight:

Products Name:	High Insulation Silicone Thermal Sheet For Car Battery	Thermal Conductivity:	1.0W/mk
Color:	Light Green	Construction & Compostion:	Ceramic Filled Silicone Elastomer / Fiberglass
Specific Gravity:	1.51g/cc	Continuous Use Temp:	-45~200℃
Keywords:	Thermally Conductive Insulator	Application:	Car Battery

Products Name:	High Insulation Silicone Thermal Sheet For Car Battery
Thermal Conductivity:	1.0W/mk
Color:	Light Green
Construction & Compostion:	Ceramic Filled Silicone Elastomer / Fiberglass
Specific Gravity:	1.51g/cc
Continuous Use Temp:	-45~200℃
Keywords:	Thermally Conductive Insulator
Application:	Car Battery

TIS100-59-A1 High Insulation Silicone Thermal Sheet For Car Battery

TIS100-59-A1 High Insulation Silicone Thermal Sheet For Car Battery

TIS100-59-A1 Series products are the high-efficiency insulation ones with thermal conduction properties.The supplement of the insulation base film made by silica gel into the heat-conduction material creates a great effect on both the insulation and heat conduction.

TIS100-59-A1 High Insulation Silicone Thermal Sheet For Car Battery 0

Features

> Highly thermal conductive 1.0W/mK
> High dielectric strength
> Low thermal resistance with high voltage isolation

> Easy release construction
> Resistant to teaars and punctures

Applications

> Car Battery & Power Supply

> Power semiconductors
> Audio and Video components

> Motor controllers

> Notebook
> Power supply
> Memory Modules
> Mass storage devices

Typical Properties of TIS100-59-A1 series
Product Name	TIS110FG-59-A1	TIS118FG-59-A1	TIS122FG-59-A1-10	Test Method
Color	Light green			Visual
Construction &Compostion	Ceramic filled silicone elastomer / Fiberglass			*******
Composite Thickness	0.01"/ 0.25mm	0.018"/ 0.45mm	0.022"/ 0.55mm	ASTM D374
Specific Gravity	1.51g/cc			ASTM D297
Continuous Use Temp	-45 to 200℃			*******
Dielectric Breakdown Voltage	>5000 Vac			ASTM D149
Dielectric Constant	4.5 MHz			ASTM D150
Volume Resistivity	4.2X10¹³ Ohm-meter			ASTM D257
Flame Rating	94 V0			E331100
Thermal conductivity	1.0 W/mK			ASTM D547

Standard Thicknesses:
0.01"/0.25mm, 0.018"/0.45mm, 0.022"/0.55mm,

Consult the factory alternate thickness.

Peressure Sensitive Adhesive:
Fiberglass with "FG" suffix.

Request adhesive one side with "A1" suffix.

Product Sizes
12" x 160'(304mm x 48.76M)
lndividual die cut shapes and custom thickness can be supplied.

Packaging Details & Lead time

The packaging of Thermal Insulation Materials

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
